AES24V MS150

AES CHARGER RK 24V / MS150 EN54-4

AES battery chargers associated with batteries allow backup power for safety sound installations for the evacuation of buildings.
Accepts currents of use from 40 to 150 A.
Controls the presence and impedance of the battery (aging).
Protects the battery from temperature variations and deep discharges.
Reports of alarms on dry contacts and locally.

Specifications

Battery CapacityBetween 38 and 225Ah
Dimensions (W x D x H)483 x 395 x 89 mm
Operating temperature-10 to +45°C at 100% of load-10 to +55°C at 75% of load
OutputsNominal Voltage 24vDC / Floating Voltage Set at half-load and at25°C: 27.2V +/- 0.5%
Outputs RelaysOutput Relay without any voltage Battery Default / Output Relay without any voltage Main Power Default / Output Relay without any voltage 24V Ouput Default
Power voltage195 - 264 V AC, 50-60 Hz
Primary Current1 A @ 195 V AC. Breaker Circuit (D curve) need to be provided Upstream
Relative Humidity20 to 95%
Weight5,4 kg
Certification ce - Majorcom
Certification rohs - Majorcom
Certification bureau veritas - Majorcom
Certification iso - Majorcom
Certification dante - Majorcom
Certification EN54 - Majorcom
