Data Sheet
Specifications
| Rated power | 240W x 1CH |
| Output voltage/impedance | 100V/41.66Ω |
| Input sensitivity | 5 dBV |
| THD(Rated Power, 1kHz) | Less than 1% |
| S/N(20kHz LPF, A-wtd) | More than 85dB |
| Frequency response (±3dB, 1W) | 20~20kHz |
| Network | Ethernet 100/1000 Base-T (RJ-45) |
| Operating temperature | -10°C ~ 40℃ |
| Power source | AC 220-240V, 50/60Hz, DC 24V |
| Power consumption | 135W |
| Weight | 8.4kg |
| Dimensions | 482(L) x 88(H) x 454(P)mm |
