DPN-240Q

Dante Digital Network Amplifiers / EN54-16 certified

  • The DPN series offers a wide choice of single or multi-channel power ratings, in line 70V/100V with galvanic isolation.
  • The amplifiers are EN54-16 certified and designed to work with the EVAMATRIX security PA system.
  • All system components are fully IP networked (audio & control) using Dante® technology.
  • Dual primary and secondary network connection for total redundancy.
  • Low power consumption, low heat dissipation for energy savings and gains in battery capacity and backup power.
  • Complete supervision of the operation of the amplifiers and all connections. Faults are reported locally on the EVAMATRIX and archived.
  • Control and supervision of the loudspeaker lines WITHOUT audio interruption with the EOL-20 end of line element
  • Control and supervision of the network link with audible and visual indication on the amplifier unit and EVAMATRIX.
  • Integrated backup amplifier channel dynamically assignable from the EVAMATRIX web interface with automatic switchover
  • 2 A/B outputs on each amp channel. The 2 outputs are supervised and individually disabled in case of failure.
  • Audio over IP, Dante® and AES67 compatible; audio sample rate is of 48 kHz with a sample sizeof 24 bits.
  • High signal to noise ratio, wide audio bandwidth, very low distortion and crosstalk.
  • DSP, digital signal processing on all amp channels from the EVAMATRIX control unit web server, including equalization, levels to optimize and customize thesound in each speaker zone.
  • Local UGA and dry contact inputs monitored for triggering of alarm conditions, alarms... Ideal for decentralized systems.
  • Dry contact inputs for local feedback of third party faults (CMSI, EAE, GTC...) in case of decentralized use.
  • Local fault outputs customizable as desired and by alarm zone.
  • An additional local analog audio input on each DPN amplifier that willbe converted and made available to the entire EVAMATRIX system.
  • The system integrates the SNMP V2c protocol (Simple Network Management Protocol) which allows a management and monitoring software to report any type of fault and status of the sound equipment.
  • The system incorporates seamless security (HTTPS, TLS1.2, SHA256, SSL, AES256 encryption and elliptic curve cryptography).

All product details

Titre 1

Titre 2

Titre 3

Titre 1

Titre 2

Titre 3

Titre 1

Titre 2

Titre 3

Titre 1

Titre 2

Titre 3

Specifications

MODELDPN-240Q
Power supply220 - 240VAC, 50/60Hz, 24VDC
Power4 x 240W RMS @ 70V/100V Class D Load Min 41.6Ω, Capacity Min 0.01uF
ConsumptionMax1 254W
1/8 power280W
Standby89W
Frequency response20Hz - 20kHz à (±3dB @ 1W)
Signal / Noise> 91dB (20kHz LPF, A-WTD)
T.H.D< 0.45% at 1kHz Power rating
Audio inputType: Balanced Euro terminal / Input sensitivity: 5 dBV (1.78 Vrms)
Ethernet (LAN)RJ45, TCP/IP protocol 100/1000 Base-T
ExtensionOutput to EVAMATRIX on RJ45 (Dante®) - Input from EVAMATRIX on RJ45 (Dante®) CAT5 cable Maximum distance: 100m
UGA inputsUGA inputs 1 ~ 4 : triggerable on a voltage (22V ~ 60V)
Dry contact inputsDry contact inputs from (1 ~ 4) : triggerable on dry contact NO/NF
Dry contact outputsDry contact outputs from (1 ~ 4) : Relay output
Speaker line outputs4-pin connector, (1ch) for channels A+B
Backup amplifier input1 input per channel, for amplifier with equal power
ProtectionCurrent protection, temperature protection, DC voltage output protection, overload
AES/EAE emergency power input24VDC
FAULT-IN inputSupervised fault input for remote fault reporting (e.g. AES/EAE)
Screen1.3’’ OLED screen
Operating temperature-10°C ~ +40°C / Humidity: 5 ~ 95%
Weight10,1kg
Dimensions (WxHxD)482 x 88 x 450mm
AccessoriesAC power cord, Euroblock connectors, Rack mount screws, User manual
Protocol and encryptionTCP/IP, Http, Https, SNMP V2c, IPv4, TLS1.2, SHA256, SSL, AES-256, Elliptic curve cryptography
