- The IP-1000AB allows to add a physical audio source (CD player, radio tuner, etc.) to the IP speaker system.
- Micro SD card slot.
All product details
Data Sheet
Leaflet
Specifications
| Audio input | |
| Maximum Input Level (Balanced) | +6dBV (2Vrms) |
| Frequency response | 20Hz ~ 20kHz (±3dB) |
| THD | ≤ 0.05% |
| S/N | ≥ 92dB |
| Contact I/O | |
| Contact Input (1CH) | Dry contact |
| Contact Output (1CH) | Dry contact (N.O : Normally Open) |
| Storage | |
| Internal | 1GB |
| MicroSD (Not included) | Up to 32GB (SDHC) |
| Network | |
| Ethernet | 10/100 BASE-TX PoE |
| Connectors | Ethernet Jack (RJ-45) |
| General | |
| Power | PoE (IEEE 802.3af) or DC Min : 8V, Max : 28V |
| Power Consumption | PoE (IEEE 802.3af) : 44~57 VDC, Max 90mA, DC : 8~28V, Max 320mA |
| Operating temperature | -20℃ ~ +50℃ |
| Weight | 0.24kg |
| Dimensions (WxHxD) | 123 x 80 x 30.6 mm |
