- Amp / Preamp 240W / 100V / 70W / 4Ω
- Class-D amplifiers with output power of 240W
- HIGH-Z (100V / 70V) and Low-Z (8Ω / 4Ω)
- Multiple inputs (three microphones / lines, two lines, two stereo / line inputs, such in, USB) and a function to control the volume of each channel
- Extin in and mix out
- Display of the input signal controlled by the channel and the level of the output LED
- Tone control (severe / acute)
- 5 Switches (zone selection switch)
- Broadcasting in priority
- TEL IN> INPUT 1> INPUT 2 = INPUT 3 = Input 4 = Input 5 = INPUT 6
- External sound cut and external carillon
- Carillon and siren
- Optional set of brackets for racking PA-212 / PA-224 amplifiers in 19’’ racks (BKT-A120)
Downloads
Data Sheet
User Manual
Leaflet
CAD Files
Specifications
Dimension (LxHxP) | 420(W) x 88(H) x 318.7(D)mm |
Frequency response | 80Hz-17kHz |
Input sensibility | -70dBu /2kΩ |
Output power | 240W |
Power consumption | 90W |
THD | Moins de 1% |
Tonality control | ±10dB |
Weight (Kg) | 9.75kg |
