• Eight channel control board
• Bargraph of 8 LED segments for each channel
• Integrated speaker
• Channel selectors
• LED indication on each switch
• Monitors eight lines 70 / 100V
• Operation 24 VDC only
• Rack assembly (2U)
Downloads
Data Sheet
User Manual
Specifications
Frequency response | 32Hz – 16kHz |
Signal input | 70V or 100V |
Power source | 24VDC |
Weight (Kg) | 3.8 |
Dimensions (W x H x D) | 482mm x 88mm x 280 mm |
